2022年无损检测ISO标准全集,8种方法93个标准,高清电子版免费获取!

文章来源:http://www.eacsonline.com/

2022高清电子版,获取方式见文后。

ISO 国际组织共有340个技术委员会,其中第135个,就是无损检测。截至今日,该技术委员会共发布93个NDT 相关的ISO标准,详情如下:

ISO/TC/135 分技术委员会
发布标准数量
ISO/TC/135/SC2
表面检测方法
14
ISO/TC/135/SC3
超声检测
20
ISO/TC/135/SC4
涡流检测
7
ISO/TC/135/SC5
射线检测
26
ISO/TC/135/SC6
泄漏检测
4
ISO/TC/135/SC7
人员认证
7
ISO/TC/135/SC8
红外热像检测
4
ISO/TC/135/SC9
声发射检测
10

标准详细目录如下:

ISO/TC 135/SC 2  Surface methods
表面检测共有14个相关标准

ISO 3057:1998
Metallographic replica techniques of surface examination
ISO 3058:1998
Aids to visual inspection — Selection of low-power magnifiers
ISO 3059:2012
Penetrant testing and magnetic particle testing — Viewing conditions
ISO 3452-1:2021
Penetrant testing — Part 1: General principles
ISO 3452-2:2021
Penetrant testing — Part 2: Testing of penetrant materials
ISO 3452-3:2013
Penetrant testing — Part 3: Reference test blocks
ISO 3452-4:1998
Penetrant testing — Part 4: Equipment
ISO 3452-5:2008
Penetrant testing — Part 5: Penetrant testing at temperatures higher than 50 degrees C
ISO 3452-6:2008
Penetrant testing — Part 6: Penetrant testing at temperatures lower than 10 degrees C
ISO 9934-1:2016
Magnetic particle testing — Part 1: General principles
ISO 9934-2:2015
Magnetic particle testing — Part 2: Detection media
ISO 9934-3:2015
Magnetic particle testing — Part 3: Equipment
ISO 12706:2009
Penetrant testing — Vocabulary
ISO 12707:2016
Magnetic particle testing — Vocabulary

ISO/TC 135/SC 3     Ultrasonic testing
超声检测共有20个标准

ISO 2400:2012
Ultrasonic testing — Specification for calibration block No. 1
ISO 5577:2017
Ultrasonic testing — Vocabulary
ISO 7963:2006
Ultrasonic testing —- Specification for calibration block No. 2
ISO 16809:2017
Ultrasonic thickness measurement
ISO 16810:2012
Ultrasonic testing — General principles
ISO 16811:2012
Ultrasonic testing — Sensitivity and range setting
ISO 16823:2012
Ultrasonic testing — Transmission technique
ISO 16826:2012
Ultrasonic testing — Examination for discontinuities perpendicular to the surface
ISO 16827:2012
Ultrasonic testing — Characterization and sizing of discontinuities
ISO 16828:2012
Ultrasonic testing — Time-of-flight diffraction technique as a method for detection and sizing of discontinuities
ISO/TS 16829:2017
Automated ultrasonic testing — Selection and application of systems
ISO 16831:2012
Ultrasonic testing — Characterization and verification of ultrasonic thickness measuring equipment
ISO 16946:2017
Non-destructive testing — Ultrasonic testing — Specification for step wedge calibration block
ISO 18563-1:2015
Non-destructive testing — Characterization and verification of ultrasonic phased array equipment — Part 1: Instruments
ISO 18563-2:2017
Non-destructive testing — Characterization and verification of ultrasonic phased array equipment — Part 2: Probes
ISO 18563-3:2015
Non-destructive testing — Characterization and verification of ultrasonic phased array equipment — Part 3: Combined systems
ISO 22232-1:2020
Non-destructive testing — Characterization and verification of ultrasonic test equipment — Part 1: Instruments
ISO 22232-2:2020
Non-destructive testing — Characterization and verification of ultrasonic test equipment — Part 2: Probes
ISO 22232-3:2020
Non-destructive testing — Characterization and verification of ultrasonic test equipment — Part 3: Combined equipment
ISO 23243:2020
Non-destructive testing — Ultrasonic testing with arrays — Vocabulary

ISO/TC 135/SC 4   Eddy current testing
涡流检测共有7个相关标准

ISO 12718:2019
Eddy current testing — Vocabulary
ISO 15548-1:2013
Equipment for eddy current examination — Part 1: Instrument characteristics and verification
ISO 15548-2:2013
Equipment for eddy current examination — Part 2: Probe characteristics and verification
ISO 15548-3:2008
Equipment for eddy current examination — Part 3: System characteristics and verification
ISO 15549:2019
Eddy current testing — General principles
ISO 20339:2017
Equipment for eddy current examination — Array probe characteristics and verification
ISO 20669:2017
Pulsed eddy current testing of ferromagnetic metallic components

ISO/TC 135/SC 5     Radiographic testing
射线检测共有26个相关标准


ISO 5576:1997
Industrial X-ray and gamma-ray radiology — Vocabulary
ISO 5579:2013
Radiographic testing of metallic materials using film and X- or gamma rays — Basic rules
ISO 5580:1985
Industrial radiographic illuminators — Minimum requirements
ISO 11699-1:2008
Industrial radiographic film — Part 1: Classification of film systems for industrial radiography
ISO 11699-2:2018
Industrial radiographic films — Part 2: Control of film processing by means of reference values
ISO 12721:2000
Thermal neutron radiographic testing — Determination of beam L/D ratio
ISO 14096-1:2005
Qualification of radiographic film digitisation systems — Part 1: Definitions, quantitative measurements of image quality parameters, standard reference film and qualitative control
ISO 14096-2:2005
Qualification of radiographic film digitisation systems — Part 2: Minimum requirements
ISO 15708-1:2017
Radiation methods for computed tomography — Part 1: Terminology
ISO 15708-2:2017
Radiation methods for computed tomography — Part 2: Principles, equipment and samples
ISO 15708-3:2017
Radiation methods for computed tomography — Part 3: Operation and interpretation
ISO 15708-4:2017
Radiation methods for computed tomography — Part 4: Qualification
ISO 16371-1:2011
Industrial computed radiography with storage phosphor imaging plates — Part 1: Classification of systems
ISO 16371-2:2017
Industrial computed radiography with storage phosphor imaging plates — Part 2: General principles for testing of metallic materials using X-rays and gamma rays
ISO 16526-1:2011
Measurement and evaluation of the X-ray tube voltage — Part 1: Voltage divider method
ISO 16526-2:2011
Measurement and evaluation of the X-ray tube voltage — Part 2: Constancy check by the thick filter method
ISO 16526-3:2011
Measurement and evaluation of the X-ray tube voltage — Part 3: Spectrometric method
ISO 19232-1:2013
Image quality of radiographs — Part 1: Determination of the image quality value using wire-type image quality indicators
ISO 19232-2:2013
Image quality of radiographs — Part 2: Determination of the image quality value using step/hole-type image quality indicators
ISO 19232-3:2013
Image quality of radiographs — Part 3: Image quality classes
ISO 19232-4:2013
Image quality of radiographs — Part 4: Experimental evaluation of image quality values and image quality tables
ISO 19232-5:2018
Image quality of radiographs — Part 5: Determination of the image unsharpness and basic spatial resolution value using duplex wire-type image quality indicators
ISO 20769-1:2018
Radiographic inspection of corrosion and deposits in pipes by X- and gamma rays — Part 1: Tangential radiographic inspection
ISO 20769-2:2018
Radiographic inspection of corrosion and deposits in pipes by X- and gamma rays — Part 2: Double wall radiographic inspection
ISO 21432:2019
Standard test method for determining residual stresses by neutron diffraction
ISO 23159:2020
Gamma-ray scanning method on process columns

ISO/TC 135/SC 6 Leak testing
泄漏检测共有4个标准
ISO 3530:1979
Vacuum technology — Mass-spectrometer-type leak-detector calibration
ISO 20484:2017
Leak testing — Vocabulary
ISO 20485:2017
Leak testing — Tracer gas method
ISO 20486:2017
Leak testing — Calibration of reference leaks for gases

ISO/TC 135/SC 7 Personnel qualification
人员认证有7个相关标准
ISO 9712:2021
Qualification and certification of NDT personnel
ISO/TS 11774:2011
Performance-based qualification
ISO 18490:2015
Evaluation of vision acuity of NDT personnel
ISO 20807:2004
Qualification of personnel for limited application of non-destructive testing
ISO/TS 22809:2007
Discontinuities in specimens for use in qualification examinations
ISO/TS 25107:2019
NDT training syllabuses
ISO/TS 25108:2018
NDT personnel training organizations

ISO/TC 135/SC 8 Thermographic testing
红外热像检测有4个标准


ISO 10878:2013
Infrared thermography — Vocabulary
ISO 10880:2017
Infrared thermographic testing — General principles
ISO 18251-1:2017
Infrared thermography — Part 1: Characteristics of system and equipment
ISO 22290:2020
Infrared thermographic testing — General principles for thermoelastic stress measuring method

ISO/TC 135/SC 9 Acoustic emission testing
声发射检测目前有10个标准
ISO 12713:1998
Acoustic emission inspection — Primary calibration of transducers
ISO 12714:1999
Acoustic emission inspection — Secondary calibration of acoustic emission sensors
ISO 12716:2001
Acoustic emission inspection — Vocabulary
ISO/TR 13115:2011
Methods for absolute calibration of acoustic emission transducers by the reciprocity technique
ISO 16836:2019
Acoustic emission testing — Measurement method for acoustic emission signals in concrete
ISO 16837:2019
Acoustic emission testing — Test method for damage qualification of reinforced concrete beams
ISO 16838:2019
Acoustic emission testing — Test method for classification of active cracks in concrete structures
ISO 18081:2016
Acoustic emission testing (AT) — Leak detection by means of acoustic emission
ISO 18249:2015
Acoustic emission testing — Specific methodology and general evaluation criteria for testing of fiber-reinforced polymers
ISO 19835:2018
Acoustic emission testing — Steel structures of overhead traveling cranes and portal bridge cranes


获取方式:
扫描二维码,加好友!
